NCR-5108T  (100M multi-mode duplex fiber) media convector used for the exchanging between Ethernet and fiber.The machine comprises 2 Ethernet port and 2 Fiber port,and expanded the LAN cable transmission distance from 100 meters to 2 kilometers. It realized the inter connections between different telecom equipment and widely been used in Telecommunication,CATV,Bandwidth network,CCTV where demands high performance and reliability network environment.

· Special  used for exchanging between Ethernet LAN cable and Fiber
· Special  made chip with low consumption,supporting over longtime frame
· Superior  Photoelectric integrated module which provide good optical and electrical  performance
· Ensure  the reliability of data transmitting,long operating life span
· Support  Internal and External:1.5U rack mount,optional installation method
· Average  of No trouble working time to 50000 hours,meet the ITU-T standard
· Integrated  after selling services, 3 years warranty,  lifetime Maintenance Service

·Standard:IEEE  802.3 10BaseT，IEEE 802.3u 100Base-TX，100Base-FX,IEEE 802.3z/AB 1000Base-T/SX/LX/ZX
· Interface:Twisted  pair cable:RJ45;Fiber:SC/ST/FC
· 100  base LED:PWR, FX 100，FX Link/Act，FDX，TX 100，TX  Link/Act
·  Transmission Speed: LAN cable:10Mbps,100Mbps,Fiber:100Mbps
· Duplex  Way: Ethernet duplex or half duplex
· Flow  control: Full duplex IIEEE 802.3x flow control:Half duplex back flow control
· LAN  Cable: Category 5,Category 5E,Category 6
· Fiber  Type: Multimode 50/125u，62.5/125u
·Power:AC:110v-240v  wide voltage input,50Hz;DC:12V 0.5A(Compatible 5-19V,6W),equipped with  USA,British,Europe,Austria total 4 types changeable plug
· Environment  Temperature：-20～65℃。
· Storage  Temperature：-20～70℃。
· Humidity：5%～90%。
 · Size：86×48×22mm((H×D×W)。

·  IEEE 802.3 Ethernet
·  IEEE 802.3U Ethernet
·  IEEE 802.3ab Ethernet
·  IEEE 802.3z Ethernet
·  IEEE 802.1d Spanning Tree

· Inter  cities  fiber optic network: Applied in  telecom and CATV data network operators
· Bandwidth  application: Applied in Financial,governmental,oil,railway,power  grid,transportation,education special networks
· Data transmission:  image, voice, data comprehensive transmission,applicable for remote education,  video conference, CCTV surveillance control signal,image and data simultaneous  transmission
